本文由 Taller de Arquitectura Contextual 授权mooool发表,欢迎转发,禁止以mooool编辑版本转载。
Thanks Taller de Arquitectura Contextual for authorizing the publication of the project on mooool, Text description provided by Taller de Arquitectura Contextual.


Taller de Arquitectura Contextual:Al Modar是一座对现有建筑改造而成的多功能餐厅。我们的目标是打造一个休闲、凉爽和放松的聚会场所。在这里,人们可以通过咖啡、食物、自然、建筑环境和社交互动感受多元的感官体验。

Taller de Arquitectura Contextual: The Founders Pavilion (Al Modar) is the result of an architectural intervention to an existing construction to transform it into a multifaceted space adapted for restaurant use. The objective was to achieve a casual, cool and relaxed meeting place where users could live a sensory experience through coffee, food, nature, the built environment and social interaction.


© Leo Espinosa
© Leo Espinosa



The pre-existing building was a small rural house of 50sqm located in one of the corners that contain the foundational square of Cholul, a community of pre-Hispanic origin belonging to the city of Mérida, southeast of Mexico.


Al Modar位于广场一角 Al Modar at the corner of the square

© Leo Espinosa



This received a modification 25 years before, in which the original roof and openings were lost. The current project proposed the demolition of the added covers and the recovery of the original structure of the stone masonry walls, which were prepared to support a double-height reinforced concrete barrel vault over the main access that extends the covered area, as well as a flat slab over the service area that supports an open terrace at the top, from which a new way of appreciating the public square is generated.


▼改造前 Before

© Leo Espinosa


▼改造后 After

© Leo Espinosa



In the overlapping of the slabs, a north-facing window is created that evacuates the hot air, introduces light and frames views towards the treetops.


▼朝北的窗户 The north-facing window

© Leo Espinosa



Both the vault and the murals on the façade, made from the scraping of layers of paint that it has received during its history, refer to the vault and characteristic murals of the 16th century Church, cataloged as a Historical Monument, that is located in front of the building.


▼拱顶和立面的壁画 The vault and the murals on the façade

© Leo Espinosa
© Leo Espinosa



85% of the tables are outdoors due to sanitary dispositions. These are divided between the backyard and the raised terrace. The interior space works with cross ventilation and is made up of a small area for diners, the service bar, the toilets and the storage and support areas.


▼分布在顶部露台的桌子 The tables of the raised terrace

© Leo Espinosa


▼室内空间 The interior space

© Leo Espinosa
© Leo Espinosa



Materiality takes up the practicality, warmth and simplicity that characterizes rural Yucatecan architecture. The stucco paintings of the original walls were preserved and restored. The lower bed of the vault exhibits the concrete of its structure, colored with the same paint as the rest of the building, while on the outside of it a burnished stucco with integrated pigment in the same tone was applied, as well as in the frames of the recovered openings.


© Leo Espinosa



The interior floors are devastated white concrete with ecocrete joints to release moisture from the floor.


© Leo Espinosa



Non-slip hammered concrete floor was laid on the raised terrace and staircase.


© Leo Espinosa



The backyard was leveled with local walkable and permeable gravel.




In the same way, blacksmithing elements with encapsulated oxide, stainless steel, apparent concrete lattice, stone blocks from the region, transparent glass and yellow screen-printed glass were used.


© Leo Espinosa
© Leo Espinosa



Cedar hardwood and regional Tzalam were used for doors and tables (respectively) and the chairs were considered white plastic.


▼门 Door

© Leo Espinosa


▼桌椅 The tables and chairs



The landscaping is an interpretation of the aesthetics of Mayan plots that stimulates the senses. The plant proposal dignifies the pre-existing trees and is consolidated by means of concrete pots, produced in the locality with endemic vegetation, concrete benches attached to the stone low walls and a water garden with a recirculation fountain.


© Leo Espinosa


▼设计动图 Animation

© TACO taller de arquitectura contextual


▼总平面图 Master plan

© TACO taller de arquitectura contextual


▼一楼平面图 Ground floor plan

© TACO taller de arquitectura contextual


▼顶楼平面图 Upper floor plan

© TACO taller de arquitectura contextual


▼正立面 Front Facade

© TACO taller de arquitectura contextual


▼剖面图 Section

© TACO taller de arquitectura contextual
© TACO taller de arquitectura contextual




项目名称:Al Modar
施工:TACO contextual architecture workshop
室内设计和景观设计:TACO taller de arquitectura contextual
团队:Carlos Patrón Ibarra、Ana Patrón Ibarra、Alejandro Patrón Sansor、Karla Gómez Luna、Libia Aguilar Coronado、Blanca Cruz、Kristell Guillen
土地面积:180.00 平方米
建筑面积:75.00 m2
建筑设计:TACO contextual architecture workshop
结构工程:Emmanuel Solís
摄影:Leo Espinosa

Project name: Al Modar
Construction: TACO contextual architecture workshop
Interior design and landscaping: TACO taller de arquitectura contextual
General team: Carlos Patrón Ibarra, Ana Patrón Ibarra, Alejandro Patrón Sansor, Karla Gómez Luna, Libia Aguilar Coronado, Blanca Cruz, Kristell Guillen
Land area: 180.00 m2
Built area: 75.00 m2
Completion year: 2021
Location: Mérida, Mexico
Architectural Design: TACO contextual architecture workshop
Structural engineering: Emmanuel Solís
Photography: Leo Espinosa
