本文由 NGHIA ARCHITECT 授权mooool发表，欢迎转发，禁止以mooool编辑版本转载。
Thanks to NGHIA ARCHITECT for authorizing the publication of the project on mooool. Text descriptions photos provided by NGHIA ARCHITECT.
NGHIA ARCHITECT：这是一个可为三代同堂的家庭提供多种不同生活方式的住宅，包括祖父母习惯的传统越南生活方式，以及已婚夫妇和孩子们熟悉的国外现代生活方式。设计考虑到家里的长辈住在这个地区已经很长一段时间，与邻居们有很强的联系，每天都与他们的熟人互动，而他们的孩子和孙子每年只去越南几次，因此必须有足够大的空间来容纳大型家庭聚会和多种社交活动。
NGHIA ARCHITECT：We were set to design a house for a three-generations family with different lifestyles between the family members. While the grandparents are used to the traditional Vietnamese lifestyle, the married couple and their children are familiar with the modern way of living in foreign countries. The elders in this family have been living in this area for a long time and have a strong connection with the neighbors and interact with their acquaintances daily while their children and grandchildren only travel to Vietnam a few times per year so big spaces to accommodate a large family gathering as well as multiple social events is a must.
由于家庭成员的生活方式、年龄和个人需求的差异，我们需要创造各种不同的空间来满足这些需求。最重要的是要有一个可以灵活地打开和关闭的大型交流空间，同时有效地连接住宅周围的自然环境以及宽阔走廊下面的庭院。
Because of the difference between the family members’ lifestyles, ages and personal needs, we need to create various spaces that meet these requirements. It is important to form large communication spaces that can open up and close down flexibly and also can connect effectively with the nature surrounding the house and the courtyard which was brought under a wide veranda.
整个住宅主要分为三个生活区，可满足家庭成员的所有基本需求。两个睡眠区分布在住宅一侧，客房设置在住宅后侧，大厨房和餐厅形成住宅核心区，作为主要交流空间，连接其他所有区域。
The whole residence provides its residents all their basic needs and being divided into three living blocks, two sleeping blocks on the side of the structure, guest rooms at the back of the house while in the heart of the house is the big kitchen and dining blocks, which serve as the main communication space and connect all other areas.
在建造过程中，大部分原有的松树林都没有被破坏。建筑的结构形态由水平向不同方向伸展，为松树留下了充足生长的空间。于是在现有的松树林下，一座花园簇拥的房子静谧生长。
During the construction of this house, most of the pre-existed pine tree forest remained untouched. While the building was designed in a way that its structure spread out in different directions horizontally, it still left room for the pine trees to thrive and underneath the existing pine forest, this house is surrounded by its own gardens.
就建筑设计而言，最大的挑战在于，如何设计一个巨大的结构使其拥有足够的空间，且仍能很好地融入周围的环境。从远处看，这个大型结构依稀只见两层屋顶的轮廓，大部分体量隐藏在屋顶之下，创造了连接内部空间与居民和周围自然的空隙空间。
In terms of architecture design, we, the architects, keep asking ourselves about how to design a massive structure but somehow it still blends in well with its surroundings. From afar, the large structure can only be distinguished by the outline of the roofs on the two levels. The building blocks hide under the roofs and create voids that connect the internal spaces with its inhabitants and the nature surrounding them.
住宅所用的主要材料是混凝土和天然木材。裸露的混凝土表面和木材图案组合旨在创造一种质朴和自然的感觉，同时确保现代生活方式的优雅和舒适。这种建筑也很特别，因为它复杂的屋顶结构超越了结构系统，给建筑重新定义了一种重力外观。30米长薄而轻的天篷沿着建筑延伸，却没有任何结构柱支撑，在厨房去前面形成充满绿色自然的开放门廊，家人们可以坐在门廊或厨房里，在晴空下欣赏树下蓝天，或在雨天感受雨声。
The main materials being used in this work are concrete and natural wood. The bare concrete surface and the wood pattern aims to create a rustic and natural feeling but still ensure the elegant and comfortable of the modern lifestyle. This construction is also special because of its sophisticated roof structure that goes beyond the structural system which gives the building a gravity redefining look. The thin and light canopy running along the length of the building creates a wide, open porch filled with green nature, and under the 30 meters long canopy there is no sign of any structural column. In front of the kitchen blocks is a wide, open porch, the residents can sit on the porch or in the kitchen and admire the blue sky under the trees or feel the rain falling outside on a rainy day.
▽总平面 Master Plan
▽各层平面图 Floor Plans
▽剖面图 Sections
项目名称：Villa LP
项目地点：越南 河内 巴维
场地面积：5000平方米
建筑面积：630平方米
完成：2021年
图片来源：Nguyen Tuan Nghia – Nam Nguyen
视频链接：https: //www.youtube.com/watch?v=BNe_AbRn4cg
Project Name: Villa LP
Project location: Ba Vi, Ha Noi, Viet Nam
Area: 5000 m2
Gross built area: 630 m2
Completion Year: 2021
Photo Credits: Nguyen Tuan Nghia – Nam Nguyen
Video link: https: //www.youtube.com/watch?v=BNe_AbRn4cg
“好的住宅设计要兼顾各成员的复杂需求，不仅要关注下一代的生活空间，更要关注长辈们的晚年养老生活需求。”
审稿编辑：Via Wang
